ABChimie 526UV LED DS140

PRODUCT DESCRIPTION

ABchimie526UV LED DS140 varnish is a transparent, one-component varnish, designed
for the protection of printed circuit boards subjected to harsh environments. It benefits
dual cure technology (UV-LED/humidity) allows cross-linking in the areas
shadow. It was developed for all applications where a fast process is required.
ABchimie526UV LED DS140 varnish can be applied by dipping, brush, pad printing,
Vaporization and, of course, selective dispensing machines, which are the ideal dispensing method.
The low viscosity of our system allows us to limit the thicknesses on the card to approximately 80
microns.
The ABchimie526UV LED DS140 varnish complies with REACH and RoHS regulations.
A certificate can be issued upon request at the following address: info@abchimie.com

FEATURES

• Excellent grip in severe weather conditions,
• Fluorescent under ultraviolet light to allow for monitoring of the varnish layer
filed,
• Temperature range from -55°C to +150°C,
• Heat-sealable varnish,
• Mold resistance,
• Excellent dielectric properties,
• IEC NF EN 61086,
• UL94-V0 (QMJU2- E308681),
• Ultra-fast polymerization under UV exposure,
• Polymerization of shaded areas with moisture,
• 0 VOC,
• Reduced floor space required compared to solvent-based solutions
• Faster processes, increased productivity,
• Use in selective deposition machines (compatible with SC200, SC280, SC300 heads and
SC400).
